| Catheter type | OTW |
| Recommended guide wire | 0.014’’ |
| Tip | Optimized entry profile, colored |
| Balloon | SCP (Semi-Crystalline Polymer), controlled compliance (4-6%), 3-fold, hydrophilic patchwork coating, 2 swaged markers (zero profile) |
| Sizes | Ø 1.5-4.0 mm; L: 20-220 mm |
| Proximal shaft | 3.9F, hydrophobic coating, coaxial design, stiffening wire |
| Distal shaft | 3.1F, hydrophilic coating, coaxial design; 150 mm length (Ø 1.5/2.0 x 20-100 mm), 75 mm length (Ø 2.0 x 140 – 220 mm and Ø2.5 – 4.0 mm) |
| Usable length | 90, 120, 150 cm |
| NP | 7 atm |
| RBP | 14 atm |
